400Gb/s OSFP SR4 100m Fiber Optic Transceiver Multi Vendor Compatible
Features
- 4x100G PAM4 retimed 400GAUI-4 electrical interface
- MPO-12 APC connector
- 4 channel VCSEL arrays and 4 channels PIN photo detector arrays
- Maximum link length of 60m on OM3 or 100m on OM4
- Hot Pluggable OSFP form factor
- Compliant to OSFP Module Specification Rev 5.0
- Compliant with CMIS 5.2
- Compliant with IEEE 802.3db
- Compliant to IEEE 802.3ck
- Power consumption is less than 9W
- Operating case temp
Commercial: 0°C to +70 °C
- RoHS compliant
Applications
- 400GBASE-SR4 400G Ethernet
- Data center
Introduction to SULITON 400Gb/s OSFP SR4 100m Fiber Optic Transceiver
The SULITON 400G OSFP Module（SLT0OPS4400GT85C） is a four-Channel, Parallel, Pluggable, Fiber-Optic OSFP for 400Gigabit Ethernet applications. This transceiver is a high-performance module for short-range data communication and interconnect application. It integrates four data lanes in each direction with 4×53.125GBd. The length of OSFP SR4 is up to 60 meters over OM3 MMF or 100 meters over OM4 MMF. This module is designed to operate over multimode fiber systems using a nominal wavelength of 850nm.
Advantage of SULTION 400Gb/s OSFP SR4 100m Fiber Optic Transceiver
The SULITON 400G SFP provides an excellent solution for high reliability, lower power consumption and excellent EMI performance allow system design with high port density. This product is RoHS compliant and is designed and tested in accordance with industry safety standards. The transceiver is Class I Laser product per U.S. FDA/CDRH and international IEC-60825 standards.
Specification of SULTION 400Gb/s OSFP SR4 100m Fiber Optic Transceiver
Part Number | SLT0OPS4400GT85C | Wavelength | 850nm |
Product Type | OSFP SR4 | Receiver Type | PIN |
Form Factor | OSFP | TX Power | -1 ~4dBm |
Connector | MPO | Extinction Ratio | >3.5dB |
Max Data Rate | 400Gbps | RX Sensitivity | <-6.4dBm |
Link Distance | 100m | Overload Sensitivity | 4dBm |
Fiber Type | MMF | Power Budget | 5.4dB |
Transmitter Type | VCSEL | Power Consumption | 9W |
Operating Case Temperature | 0~70C | DDM/DOM | Supported |
