25GBASE-LR SFP28 1310nm 20km DOM Duplex LC/UPC SMF Optical Transceiver Module Cisco SFP-25G-LR-S Compatible
Features
- Compliant with SFF-8431 andSFF-8472
- Compliant with SFP28 MSA Specification
- Digital Diagnostic Monitoring available
- Uncooled 1310nm DFB Laser
- Up to 25.78Gb/s data links
- Up to 20km on 9/125μm SMF
- Duplex LC connector compliant
- Single +3.3V DC power supply
- Hot-pluggable SFP footprint
- Class 1 laser safety certify
- Operating case temp
Commercial: 0°C to +70 °C
Industrial: -40 ~ +85 °C
- RoHS compliant
Applications
- High speed storage area networks
- 25G high speed interconnection
- Switch to Switch Interface
- Other Optical Links
Introduction to Cisco SFP-25G-LR-S Compatible 25GBASE-LR SFP28 1310nm 20km DOM Duplex LC/UPC SMF Optical Transceiver Module
SLT0SPLR025GT31x
The SULITON 25g SFP28 LR Module is an enhanced SFP28 fiber optic transceiver with dual LC connector supporting transmission at 25Gb/s up to 20 kilometers of single mode fiber. The transceiver is compliant IEEE 802.3cc 25GBASE-LR and 25G CPRI 10 standard. Digital diagnostics monitoring (DOM) functionality (alarm and warning features) is integrated into the design via an I2C serial interface per the Multi-Source Agreement (MSA) SFF-8472.
Advantage of Cisco SFP-25G-LR-S Compatible 25GBASE-LR SFP28 1310nm 20km DOM Duplex LC/UPC SMF Fiber Optic SFP
The SULITON 25g SFP28 LR Transceiver provides an excellent solution for high reliability, lower power consumption and excellent EMI performance allow system design with high port density. This product is RoHS compliant and is designed and tested in accordance with industry safety standards. The transceiver is Class I Laser product per U.S. FDA/CDRH and international IEC-60825 standards.
Specification of Cisco SFP-25G-LR-S Compatible 25GBASE-LR SFP28 1310nm 20km DOM Duplex LC/UPC SMF Optical Transceiver Module
Part Number | SLT0SPLR025GT31x | Wavelength | 1310nm |
Product Type | SFP28 LR | Receiver Type | PIN |
Form Factor | SFP28 | TX Power | -2~4dBm |
Connector | LC | Extinction Ratio | >3.5dB |
Max Data Rate | 25.78125Gbps | RX Sensitivity | <-13dBm (5E-5) |
Link Distance | 20km | Overload Sensitivity | 2dBm |
Fiber Type | SMF | Power Budget | 11dB |
Transmitter Type | DFB | Power Consumption | 1.5W |
Operating Case Temperature | -40~85C | DDM/DOM | Supported |
Please click here to DOWNLOAD PDF DATASHEET of Cisco SFP-25G-LR-S Compatible 25GBASE-LR SFP28 1310nm 20km DOM Duplex LC/UPC SMF
